Parameters
| Inlet/outlet | 2″F |
| Drain | 1.5″F |
| Base | 4″-8UN |
| Riser pipe | 1.5″D-GB |
| Water treatment capacity | 10 m3/h |
| Tank diameter range | 10″～24″ |
| Water pressure | 0.15MPa～0.6MPa |
| Water temperature | 5℃～50℃ |
| Water turbidity | ＜20FTU |
| Environment temperature | 5℃～50℃ |
Product Features
– Highly vitrified and corrosion-resistant sealing end faces are used for opening and closing.
– No water passes through the valve during the rinsing process of the single tank type.
– Flow path design is reasonable: service → quick wash → backwash → quick wash → backwash → service.
– Can be converted to a side-loading valve with side-loading connector.
– Can be operated under pressure with no leakage.
Applications
– Residential filtration system
– Swimming pool filtration equipment
– Activated carbon or sand filtration in RO pre-treatment filtration systems
